Garmin G3X Touch
™
Pilot’s Guide for Certified Aircraft
190-02472-00 Rev. D
34
System Overview
System
Overview
Flight
InstrumentsEIS
CNS
Interface
GPS
Navigation
Flight
Planning
Hazard
Avoidance
Additional
FeaturesAFCSAnnun/AlertsAppendixIndex
TRANSPONDER
If configured to ‘Set By Pilot’ in configuration mode, (refer to the Installation Manual
for configuration information) the pilot can change the Flight ID and enable/disable
ADS-B Transmit from the Transponder Setup Page and the Transponder Pop-up Window.
Setting the Flight ID:
1)
Press the MENU Key twice.
2)
Touch Setup > XPDR.
3)
Touch the ‘Flight ID’ Field.
4)
Enter the Flight ID and touch Enter.
Or:
1)
Touch the Transponder on the PFD.
2)
Touch the ‘Flight ID’ Field.
3)
Enter the Flight ID and touch Enter.
Enabling/disabling ADS-B Transmit:
1)
Press the MENU Key twice.
2)
Touch Setup > XPDR.
3)
Touch the ‘ADS-B Transmit’ Field.
4)
Touch Enabled or Disabled.
DATA BAR SETUP
Displaying the Data Bar Setup Page:
1)
Press the MENU Key twice.
2)
Touch Setup > Data Bar.
MODE BUTTON SCREEN SIDE
Determines which side of the display the Mode Button is shown. Settings
are Auto, Left, and Right.
COM RADIO SCREEN SIDE
Adjusts the position of the COM Radio control to either the Left or Right side of
the Data Bar. This setting is only allowed for single COM radio installations (with dual
COM radio installations, COM 1 is always on the left and COM 2 is always on the
right).
