GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A228 - Rotation Motor
Page no. 1243 Chapter 9
JC-DR-A-228.fm
Job Card D/R A228 - Rotation Motor Chapter 9
1SUPPLIES
Rotation Motor
2TOOLS
• Standard Tool Box
• Hub extractor
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 75 minutes
4 SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
5 PREREQUISITES
• Lower the arm for good access to the Rotation Motor (1).
• Switch off the Gantry power.
• Remove the arm and the front covers (refer to Job Card PHY
A044 - Remove/Reinstall Gantry Covers on page 523).
• Loosen and remove the Gantry curtain (refer to Job Card D/R
A208 - Gantry Curtains on page 1193).
1
