Chapter 4 Page no. 340
Chap-Pre-Requirements.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Pre-Installation System Requirements
9. PLANNING FOR STORAGE
9-1. Temporary Storage in the Hospital
!
Notice:
There is normally a short delay (e.g., overnight) between the delivery of the equipment and its in-
stallation.
If this delay is not short (more than two days), it is essential that a suitable storage room is
available to receive the equipment in its crates.
Refer to section 1 Environmental Requirements for information on the environment required.
9-2. Packing Information
The table below lists the main dimensions and masses of shipping crates.
TABLE 6 - SHIPPING DIMENSIONS AND MASSES.
Item Dimensions in mm (inches) Mass in
kg (lbs)
Depth Width Height
Crate1 2066 (81.34) 848 (33.39) 2292 (90.24) 641 (1410.2)
Crate 1 includes the Gantry and the Generator Cabinet and the ramp for removing the Gantry, Generator and
Control Station
Crate 2 1110 (43.70) 770 (30.31) 1850 (72.83) 210.5 (464.07) for
truck transportation
without side covers
and lid
223.5 (492.73) for
plane/boat trans-
portation with side
covers and lid
Crate 2 includes the Control Station
Crate 3 872 (34.33) 2270 (89.37) 260 (10.24) 104.4 (229.68)
Crate 3 includes the box containing the Detector. (20 kg, D=766 (30.16) , W= 840 (33.07), H =654 (25.39) and
the Radiation Screen in its protective packaging
Crate 4 720 (28.35) 1300 (51.18) 1975 (77.76) 147 (323.4) *
Crate 4 includes the Accessories Cabinet, which includes the LCD Monitor, X-ray Console and all the Accesso-
ries (boxed) . * - The contents can vary, and the mass can be slightly different to 147 kg.
