GE Healthcare Senographe DS Revision 1 Service Information and Procedures Class A 2385072-16-8EN FRU/Component Index - Gantry
FRU/Component Index - Gantry Chapter 3
Class Component Description Reference Comp. Loc FD Cabl CL FRU Trac D/R
15 Emergency kit-Fuse 0.125A 99184799 FRU Y
15 Emergency kit-Fuse 6.25A 99184453 FRU Y
15 Fuse, 250 Vac, 6.25 A, Delay
(F1 on PDU Board)
46-170021P60 Loc
page
290
CL
page
290
FRU Y D/R
page
1109
15 Fuse, 250 Vac, 0.5A, Delay
(F3 on PDU Board)
46-170021P31 Loc
page
290
CL
page
290
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 2A, Delay
(F4 on PDU Board)
46-170021P30 Loc
page
290
CL
page
290
FRU Y Trac N D/R
page
1109
15 Fuse, 250 Vac, 125 mA, Delay
(F5 and F6 on PDU Board)
5344386-2 Loc
page
290
CL
page
290
FRU Y Trac N D/R
page
1109
15 Fuse, 60 Vac, 0.3 A, Resettable
(F1 on Compression Board, and
F1 on Tilt Board)
5314541-5 Loc
page
288
FRU N Trac N D/R
page
1109
15 Fuse, 60 Vac, 0.3 A, Resettable
(F2/F3 on Compression Board,
and F2/F3 on Tilt Board)
2214421 Loc
page
288
FRU N Trac N D/R
page
1109
15 Optical Fork-Lift-Lower 2345940 Loc
page
192
FD
page
76
FRU Y Trac N D/R
page
1171
15 Optical Fork-Lift-Upper 2345937 Loc
page
192
FD
page
76
FRU Y Trac N D/R
page
1167
15 Optical Fork-Rotation 2345966 Loc
page
191
FD
page
76
FRU Y Trac N D/R
page
1231
15 Potentiometer-Compression +
W303
2345909-2 Loc
page
194
FD
page
77
FRU Y Trac N D/R
page
1289
