GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A288 - Collimator Lamp
Page no. 1383 Chapter 9
JC-DR-A-288.fm
Job Card D/R A288 - Collimator Lamp Chapter 9
1SUPPLIES
Collimator Light Assembly. New centering device lamp (only genuine part number 2377836 must be
used, to ensure correct light intensity, easy filament centering and reliability).
2TOOLS
Standard Tool Box including a small Pozi screwdriver
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 2 hours
4 SAFETY PRECAUTIONS
Not applicable.
5 PREREQUISITES
• Rotate the arm to 0° and move it to its comfortable working
position to access to the Collimator Lamp (1).
• Switch off the Gantry power.
• Remove the tube cover (refer to Job Card PHY A044 -
Remove/Reinstall Gantry Covers on page 523) to access
the Collimator (1).
1
To Next Page
