GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A244 - Compression Motor with Encoder and Compression Belt
Page no. 1297 Chapter 9
JC-DR-A-244.fm
Job Card D/R A244 - Compression Motor with Encoder and Compression
Belt Chapter 9
1SUPPLIES
• 1 Compression Motor
• 1 Compression Belt
2TOOLS
• Standard Tool Box
• Hub extractor
• Mammography compression scale with digital display
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 45 minutes
4 SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
5 PREREQUISITES
• Lower the arm until you have good access to the Com-
pression Motor (1).
• Switch off the Gantry power.
• Remove the arm covers (refer to Job Card PHY A044 -
Remove/Reinstall Gantry Covers on page 523).
1
