GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A009 - Opposite Side Rotative Arm Installation
Page no. 415 Chapter 6
JC-PHY-A-009.fm
Job Card PHY A009 - Opposite Side Rotative Arm Installation Chapter 6
1SUPPLIES
• Spare USB extension cable connected to the Control Station framework below the keyboard.
• Left stop bracket (PN 5235174-2) : one ring labeled L.
Note:
The left stop bracket (PN 5235174-2) can be found in the Accessories box that is delivered with
the Senographe system. The Accessories box (located in the large wooden Accessories cabinet)
contains the ADS/IDC Software, Loopback Kit, Service Documents, etc..
2TOOLS
• Standard Tool Box
• Sisfle Rotative Arm Installation Tool (FE supply)
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 1 hour
4 SAFETY PRECAUTIONS
None
5 PREREQUISITES
None
L
To Next Page
