GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Cable Lay-out and Pin-out
Page no. 299 Chapter 3
Cables.FM
Cable Lay-out and Pin-out Chapter 3
This section lists Senographe system internal and external connecting cables.
1. GANTRY CABLING
1-1. W001 - Earth Cable 1
MPCB box to Ground bar G301.
1-2. W002 - Earth Cable for EMC Filter E101
MPCB box to EMC filter E101.
1-3. W004 - Earth Cable for AC/DC Module Board PS101
MPCB box to AC/DC Module board PS101.
1-4. W005 - Earth Cable for AC/DC Converter Module
MPCB box to AC/DC Converter Module.
1-5. W006 - Earth Cable for Bulkhead Cover
MPCB box to bulkhead cover.
1-6. W101 - SYS-Bus 1 PDU Board to Interface Board
Connector: B20B-PHDSS 20 points - two in parallel
PDU Board PL101 J8 to Interface Board PL104 J2:
Pin N° Signal Name Signal description
J2-1 H-Expose Enable RT-CAN Diff 5/2.5V
J2-2 L-Expose Enable RT-CAN Diff 2.5/0V
J2-3 Spare
J2-4 0 Power Supply Ground
J2-5 H-Expose Command RT-CAN Diff 5/2.5V
J2-6 L-Expose Command RT-CAN Diff 2.5/0V
J2-7 Ground Ground
J2-8 P Reset Command RT 0/+5V
J2-9 H-Xray On RT-CAN Diff 5/2.5V
J2-10 L-Xray On RT-CAN Diff 2.5/0V
J2-11 P Power On Command/reserved
To Next Page
