GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A246 - Manual Compression Brake
Page no. 1301 Chapter 9
JC-DR-A-246.fm
Job Card D/R A246 - Manual Compression Brake Chapter 9
1SUPPLIES
Manual Compression Brake
2TOOLS
• Standard Tool Box
• Mammography compression scale with digital display
3 REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: 30 minutes
4 SAFETY PRECAUTIONS
WARNING
The Gantry must be powered off.
5 PREREQUISITES
• Lower the arm to obtain good access to
the Manual Compression Brake (1).
• Switch off the Gantry power.
• Remove the paddle.
• Remove the compression covers (Refer to
Job Card PHY A044 - Remove/Reinstall
Gantry Covers on page 523).
1
To Next Page
