Figure 4-115 Installing temperature sensors
----End
4.2.9.5 Installing Remote T/H Sensors (33010516) for Smart Cooling
Products
T/H sensor conguration depends on the number of smart cooling products. (For
example, if there are three smart cooling products, three T/H sensors are
congured.)
4.2.9.5.1 T/H Sensor Layout
● The gure is for reference only. Install the devices based on site requirements.
● The NetCol remote T/H sensors are attached to the leftmost and rightmost IT cabinets
near aisle columns.
● Installing a T/H sensor when only one NetCol is congured
