The ngerprint and card reader with a key pad is connected to the access actuator by a network
cable.
Step 5 Check that cables are correctly connected.
Step 6 Secure the
ngerprint and card reader with a keypad to the baseplate, as shown
by (5) and (6) in Figure 4-169.
----End
4.2.9.15 (Optional) Installing an In-Room Fingerprint and Card Reader
Context
● The BOM number of a
nger and card reader is 02070173.
● It is recommended that the device be installed outside a room 1.4-1.6 m
above the
oor
● Do not install the product in a place with heavy dust or exposed to sunlight.
Procedure
Step 1 Remove the screws (set aside) from the ngerprint and card reader and take o
the baseplate, as shown by (1) in Figure 4-171.
Figure 4-171 Installing a
ngerprint and card reader
Step 2 Mark the mounting holes using a marker, and drill holes using a hammer drill.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 210
