Step 6 Insert the ECC800-Pro main control module into the slot.
Step 7 Tighten the screws on both sides of the panel of the ECC800-Pro main control
module.
Step 8 Connect the signal cables to the panel of the new ECC800-Pro main control
module based on the recorded information.
----End
6.4.4.5 Replacing a Smart ETH Gateway
Prerequisites
● Tools: ESD wrist strap, ESD gloves, Phillips screwdriver, step ladder, labels,
marker
● Material: A spare smart ETH gateway of the same model is available and
functional.
Context
A smart ETH gateway can be installed in the following two positions based on the
project conditions:
● If M-shaped cable troughs are deployed for the module, install the smart ETH
gateway on the M-shaped cable trough on the top of the Converged Cabinet.
● If two smart ETH gateways are congured, install them in positions shown
in Figure 6-49.
● If three smart ETH gateways are congured, install two of them in
positions shown in Figure 6-49, and install the remaining one on the M-
shaped cable trough of an adjacent cabinet.
FusionModule800 Smart Small Data Center
User Manual 6 O&M
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 461
