Huawei FusionModule800 User Manual

Step 3 Ensure that Enable linkage control function is Yes.
Step 4 On the Linkage Group tab page, set Link re control with Cabinet Electronic
Clasp lock open to on.
NO TE
Select Link re control with Cabinet Electronic Clasp lock open under Linkage Group. If its
value is on, the corresponding logic congurations under Linkage Logic List are available. If its
value is
o, the corresponding logic congurations under Linkage Logic List are unavailable.
Step 5 Modify the AI/DI_2 signal name.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose System Settings > Signal Name Modify. The Batch Signal
Conguration page is displayed.
3. Set Device type to ECC800, set Device name to ECC800, and click OK.
4. On the query result tab page, set the new signal name of AI/DI_2 to Fire and
click Submit.
Step 6 Enable the AI/DI device.
1. Choose Monitoring > System > ECC800 > Running Parameters > AI/DI_2
Port Settings.
2. Set Fire sensor to Enable. Click Submit to access the AI/DI_2 setting page.
3. Select Fire sensor type and set it to Normal Open or Normal Close as
required.
4. Click Unhide All Advanced Signals, and click Power Supply Parameters.
Ensure that I power supply enable(AIDI_2/COM1/AIDI_4/COM3) is Enable.
5. Click Submit.
----End
Follow-up Procedure
After the
re alarm is cleared, you need to manually close the IT cabinet door.
After the door is closed, the door open alarm is cleared.
5.3.13 (Optional) NetEco Management
5.3.13.1 NetEco6000 Management
5.3.13.1.1 Connecting a Communications Cable
Procedure
Step 1 Connect the communications cable to the WAN1 port on the ECC800-Pro.
FusionModule800 Smart Small Data Center
User Manual 5 Power-On Commissioning
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 336
