Figure 4-214 Routing a signal cable
----End
4.3.6.5 (Optional) Connecting Cables for the In-Room Access Control System
Prerequisites
● The required cables have been prepared.
● It is recommended that cables of the in-room access control system be routed
through a trough in a wall.
Cables installed on the surface of a wall need to be routed through a pipe for protection.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 242
