Huawei FusionModule800 User Manual

2. In the Domain area which is below the navigation tree, drag a managed
domain icon to the required position in the view.
NO TE
You can adjust the shape of Room, Building–ShapeNode, Floor–ShapeNode,
Container–ShapeNode, and NetecoSite. Holding down the Shift key and the left
mouse button and then clicking on the corresponding lines can increase the small
yellow dot. You can drag the small yellow dot to adjust the shape of the managed
domain icon.
To delete a domain, click the domain icon and select Delete under
.
3. In the right side of the view area, set Management Info.
Congure parameters
as required. The parameters marked with asterisks (*) are mandatory.
NO TE
You can congure Management Info, Electricity Info, and Refrigeration Info for the
equipment room management domain.
4. Click on the toolbar.
Repeat steps Step 2.1 to Step 2.4 until the conguration is complete.
Step 3 Click on the toolbar.
----End
5.3.13.1.9 Adding a Smart Module
This section describes how to create a smart module in the root node, subnet,
equipment room, container, or site management domain.
Prerequisites
● You have logged in to the NetEco client using a web browser.
● You have created management domains in Data Center Planning. For
detailed operations, see
Creating a Domain .
Procedure
Step 1 Choose System > Conguration > Data Center Planning from the main menu.
The Data Center Planning page is displayed.
Step 2 Choose the management domain where you want to add a smart module from
the navigation tree on the left.
Step 3 Click Domain. The infrastructure area is displayed.
Step 4 Select Modular from the Type drop-down list.
Figure 5-74 Selecting Modular
FusionModule800 Smart Small Data Center
User Manual 5 Power-On Commissioning
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 343
