Figure 4-196 Cutting a notch in a wire bushing
Cables can be bound to the side panel or mounting bar of the Converged Cabinet.
Figure 4-197 Cable binding position inside the Converged Cabinet
(1) Place binding cables routed across the cabinet interior
4.3.5.1.2 (Optional) Connecting Cables to the ATS Subrack
1. Connect the ATS input power cables.
Connect the ground cable rst.
2. Connect output power cables from the ATS to the Converged Cabinet.
FusionModule800 Smart Small Data Center
User Manual 4 Installation Guide
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 226
