Huawei FusionModule800 User Manual

3.4.4.2 Server
The NetEco can be deployed on one of the following servers according to the
management capability requirement.
Table 3-62 Server
Model Conguration
TaiShan 200 (Model 2280)
standard conguration
2 x Kunpeng 920 48-core@2.6 GHz, 4 x 32
GB memory, 2 x 1.2 TB + 8 x 1.8 TB drives
TaiShan 200 (Model 2180) basic
conguration
1 x Kunpeng 920 32-core@2.6 GHz, 2 x 32
GB memory, 2 x 1.2 TB drives
2288X V5-H22X-standard
conguration
2 x 5218 16-core@2.3 GHz CPU, 4 x 32 GB
memory, 2 x 1.2 TB + 8 x 1.8 TB SAS drives
2288X V5-H22X-basic
conguration
2 x 4208 8-core@2.1 GHz CPU, 2 x 32 GB
memory, 2 x 1.2 TB SAS drives
3.4.4.3 LAN Switch
Select LAN switches based on site requirements.
Table 3-63 LAN switch
Model
Maximum Number of Ports
S5331-H24P4XC Twenty-four 10/100/1000BASE-T Ethernet ports, four
10GE SFP+ ports
S5731-H24P4XC Twenty-four 10/100/1000BASE-T Ethernet ports, four
10GE SFP+ ports
3.4.5 (Optional) Edge Data Center Management System
The edge data center management system monitors the running status of the
entire network on the GIS home page. After an abnormal site is detected, you can
double-click it to access the site monitoring page. Environment, energy
consumption, key device, alarm, and security monitoring is provided on the site
monitoring page.
● Environment monitoring: Monitors the temperature, humidity, water, and
smoke.
● Energy consumption monitoring: Displays the PUE and load rate of sites in
real time.
● Key device monitoring: Monitors the UPS, air conditioners, and related power
distribution devices in real time, and displays the energy
ow diagram and air
conditioner link diagram.
FusionModule800 Smart Small Data Center
User Manual 3 System Architecture
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 87
