3 System Architecture
3.1 Structure System
Figure 3-1 Cabinet system
(1) IT cabinets
(2) Camera mounting kit on
the enclosed framework
(3) Gas spring
(4) Side sealing plate (5) Cabinet electronic clasp
lock
(6) Converged Cabinet
3.1.1 Cabinet
Cabinets are classied into the Converged Cabinet, IT cabinet, and network
cabinet.
