Huawei FusionModule800 User Manual

NO TE
1 in NetCol5000-A1 is variable and subject to changes with the smart cooling product
connection sequence. The displayed value prevails.
Step 3 Set the DIP switch address of the T/H sensor, see Set addresses.
Step 4 Choose Monitoring > Cooling > NetCol5000-A1 > Running Parameters >
Temp/Hum Sensor Parameters, set Cold-aisle sensor 1 to Enable.
----End
5.2.2.2 Setting Teamwork Control Parameters
Context
Teamwork control parameters have the following bidirectional coupling
relationships:
Number of running air conditioners in this group ≤ Number of air conditioners in
this group
● Teamwork group no.: Group the smart cooling products in adjacent areas as
one, that is, assign one teamwork control number for them. At most four
teamwork control groups can be assigned (1–4).
● Air conditioner address: The addresses for the smart cooling products in the
same group cannot be the same (address range 1–32). The smart cooling
product addressed 1 is the master one that collects, processes, and delivers
data. You are advised to set the value to an integer in the range of 1 to the
number of smart cooling products in the current group.
Procedure
Step 1 Log in to the ECC800-Pro WebUI as admin.
Step 2 Choose Monitoring > Cooling > NetCol5000-A1 > Running Parameters >
Teamwork Settings to display the page for teamwork setting.
NO TE
1 in NetCol5000-A1 is variable and subject to changes with the smart cooling product
connection sequence. The displayed value prevails.
Step 3 Set teamwork control parameters.
Table 5-1 Setting teamwork control parameters for two smart cooling products
Parameter
Smart Cooling Product No.
1 2
Teamwork function Enable Enable
Teamwork group no. 1 1
Air conditioner address 1 2
FusionModule800 Smart Small Data Center
User Manual 5 Power-On Commissioning
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 259
