Huawei FusionModule800 User Manual

6.4.4.1 Replacing an ECC800-Pro Main Control Module
Prerequisites
NO TICE
● The ECC800-Pro main control module is hot-swappable.
● Before disconnecting cables from the ECC800-Pro main control module, label
the cables based on the corresponding ports.
● Tools: ESD wrist strap, ESD gloves, Phillips screwdriver, labels, marker
● Materials: A spare undamaged and undeformed ECC800-Pro main control
module of the same model is available.
Procedure
Step 1 Use the Back Up Current Settings function to record the ECC800-Pro
conguration information or manually record the information.
Path: Maintenance > Conguration File > Back Up Current Settings
NO TE
If the main control module is damaged, login may fail and backup cannot be performed.
Step 2 Label each cable and antenna based on the corresponding ports on the ECC800-
Pro main control module.
Step 3 Remove the cables and antenna from the ECC800-Pro main control module.
Step 4 Loosen the captive screws on both sides of the ECC800-Pro main control module
and pull the handles on both sides of the module to remove the module.
Figure 6-42 Removing an ECC800-Pro main control module
Step 5 (Optional) Remove the Micro-SD card and SIM card from the corresponding slots
of the ECC800-Pro main control module.
Step 6 (Optional) Install the removed Micro-SD and SIM card in the corresponding slot of
the new ECC800-Pro main control module.
FusionModule800 Smart Small Data Center
User Manual 6 O&M
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 457
