Indica
tor
Color Name Status Description
Blinking The indicator blinks at
super short intervals for
0.5s (blinking at 10 Hz, on
for 0.05s and then o for
0.05s) and then turns o
for 0.5s. The cycle lasts for
5s.
ALM Red Alarm
indicator
Steady on The PoE output current is
overloaded.
O The PoE output is normal
or not connected.
3.4.3.7 (Optional) eLight
The eLight system consists of the eLight power system, eLight actuator, eLight
strip light, and cables.
Figure 3-33 eLight strip light
Figure 3-34 eLight actuator
The appearance of the eLight actuator depends on the actual delivery.
FusionModule800 Smart Small Data Center
User Manual 3 System Architecture
Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd. 64
