Operating elements for driving
3.2 Short description of the operating elements
3 - 32 3 112 993 en Operating manual GMK 6400
12.07.2013
Switches and
buttons
For switches and buttons, the terms down and up are used.
Regardless of the fitting position (vertical, horizontal, diagonal, perpendicu-
lar or turned), the following always applies:
3.2.2 General notes on the operating elements
Some switches have a lock button (1). The lock button is not mentioned
again during operation. The following applies to all switches with a lock but-
ton:
– Down: press (1) – next to the symbol
–Up: press (2) – opposite the symbol
– Switching on: – First press the lock button
– then press the lower switch down
– To switch off: Press upper switch down until the lock button latches
into place
