Crane operation
11.4 Settings and displays for crane operation
Operating manual GMK 6400 3 112 993 en 11 - 109
12.07.2013
11.4.6 Using the slewable spotlights
With the relevant equipment, the slewable spotlights (1) are located on the
main boom. They are controlled from the crane cab.
Switching on
• Press switch (1) down
Switching off
• Press switch (1) up
To direct the spotlights forwards
• Press button (2) up
To direct the spotlights backwards
• Press button (2) down
The direction of the spotlights will be adjusted
until you let go of the button or they reach
their end position.
G
Risk of accident due to being dazzled during on-road driving
When driving on the road, always direct the spotlight in such a way that the
reflector points downwards. In this way, you can prevent yourself and other
drivers from being dazzled and causing accidents.
