Driving modes and rigging for on-road driving
6.5 Installing/removing the supporting box
6 - 64 3 112 993 en Operating manual GMK 6400
12.07.2013
6.5.6 Disconnecting/establishing the hydraulic connection
The hydraulic connection between the supporting box and carrier consists
of two hoses with couplings.
Always close off hoses or connections you do not need with appropriate
caps.
Disconnecting
•
Remove the hoses (
2
) from the connec-
tions (
1
).
• Place the hoses in the clamp (3).
Establishing
• Remove the hoses (2) from the holder (3).
• Connect the hoses to the connections (1).
The assignment is defined by the size.
