Rigging work
12.5 Starting the engine for driving for rigging work
Operating manual GMK 6400 3 112 993 en 12 - 25
12.07.2013
12.5.2 Starting/turning off the engine from the crane cab
Requirements The following requirements must be met before you can start the engine
from the crane cab:
– The hand-held control has been disconnected and bridging plugs have
been plugged into all superstructure and carrier sockets
– The carrier ignition is switched off and the ignition key is removed. The
lamp (1) in the crane cab has gone out
– The superstructure ignition has been switched on for approx. 30 seconds
Starting the
engine
All activities and inspections required to start the engine must be carried out
before starting the engine;
à p. 4 - 1.
• If necessary, open the main menu ö and press the (1) button once.
The
Outriggers submenu opens
• Press the (1) button down once
The carrier ignition is turned on:
– The indicator lamp in the button (1)
flashes
– The symbol (2) turns green
• Press the (5) button once. The engine starts
When the engine is running:
– The symbols (3) and (4) are displayed
– The lamp in the button (1) lights up
s
