Driving
5.4 Off-road driving
5 - 60 3 112 993 en Operating manual GMK 6400
12.07.2013
5.4.2 Operating the level adjustment system
You can use the level adjustment system to set the on-road driving level,
change the overall level and incline the truck crane.
Opening the
submenu
You can only open the
Level adjustment system submenu when the current
speed is below approx. 5 km/h (3 mph).
• If necessary, open the main menu ö and press the (1) button once.
This opens the
Level adjustment system submenu.
• Check that the symbol (1) is green (suspension on).
• If the symbol (1) is red, press the button (2) once to switch on the suspen-
sion
When the suspension has been switched on, you can:
– Set the on-road driving level,
– Pre-select the suspension struts and change the vehicle level.
If the symbol (1) is shown for an error during a level adjustment, refer to
Manitowoc Crane Care.
