Driving modes and rigging for on-road driving
6.4 Installing/removing outrigger beams
Operating manual GMK 6400 3 112 993 en 6 - 51
12.07.2013
6.4.10 Transporting the outrigger beams
•
For transportation, only use a separate vehicle with sufficient lifting
capacity. Transport dimensions and weight;
à p. 1 - 10.
• Load the separate vehicle in such a way that the weight is evenly distrib-
uted.
• Load the outrigger beam so that it that does not endanger other traffic.
When the outrigger pads are mounted
• Place the outrigger beam onto a suitable device (1).
• Secure the outrigger beam from slipping.
When the outrigger pads are dismounted:
• Lay the outrigger beam onto the side.
• Secure the outrigger beam from slipping.
• Lay the outrigger pads onto the separate vehicle and secure them for
transportation.
S
Risk of damage to the outrigger beams and outrigger pads
When outrigger pads are mounted, always use a device to set them down.
If you lay the outrigger beams onto the side, connections may tilt and
become damaged.
