Driving modes and rigging for on-road driving
6.3 Removing/installing main boom
Operating manual GMK 6400 3 112 993 en 6 - 11
12.07.2013
6.3 Removing/installing main boom
This section applies only to truck crane which are fitted with the pulling
devices for removing/mounting the main boom.
Additional equip-
ment required
In addition to the pulling devices, you also need the following accessories:
– A derricking cylinder support (1)
– A tightening belt (4)
– A lifting device (3)
– Lifting gear (2)
as well as
– An auxiliary crane with sufficient lifting
capacity
– A separate vehicle with sufficient load bear-
ing capacity and loading area
Transport dimensions and weight;
à p. 1 - 10.
G
Risk of accident when removing/installing the main boom without pulling
devices
Only remove or install the main boom if the truck crane is equipped with
the factory-installed pulling devices and with the necessary accessories.
Without this factory-installed pulling device, the main boom may only be
removed by Manitowoc Crane Care.
