Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual GMK 6400 3 112 993 en 9 - 91
12.07.2013
9.2.18 Rated capacity limiter (RCL)
Control unit This section contains the operating elements that are the same for all menus
opened.
Buttons F1 to F14
The function of buttons F1 to F14 is shown on the symbol next to or above
the button. After the button is pressed, the function displayed is executed
provided it has been released.
Error
Opening Errors submenu
The lamp (1) lights up or flashes.
Exiting submenu/input mode
The lamp (1) lights up.
s
–On: Error has occurred
– Off: No errors
à p. 11 - 39
– Press the button 1 x: This opens the
Errors submenu
à p. 14 - 25
– Press the button 1 x: – The opened submenu closes – the menu from
the next highest level is opened
– Input mode is deactivated
