Manitowoc GROVE GMK 6400 User Manual

Overview
1.5 Technical data
1 - 10 3 112 993 en Operating manual GMK 6400
12.07.2013
1.5.3 Dimensions and weights of removable parts
This section contains the dimensions and weights of the parts that can be
removed for on-road driving;
à Driving modes, p. 6 - 1.
Spare wheel
Outriggers
Designation
Length x width x height
in m (ft)
Weight in kg
(lbs)
Spare wheel 385/95 R 25 1.36 x 1.36 x 0.40
(4.45 x 4.45 x 1.30)
245
(540)
Spare wheel 445/95 R 25 1.50 x 1.50 x 0.45
(4.95 x 4.95 x 1.50)
310
(685)
Spare wheel 525/80 R 25 1.50 x 1.50 x 0.53
(4.92 x 4.92 x 1.74)
355
(785)
Designation
Length x width x height
in m (ft)
Weight
in kg (lbs)
Plastic outrigger pad
diameter
0.70 x 0.14
(2.30 x 0.46)
43
(95)
Front outrigger
1)
,
complete per packet
2.98 x 0.37 x 1.20
(9.78 x 1.21 x 3.94)
1 252
(2760)
Rear outriggers
1)
,
complete, per packet
2.98 x 0.37 x 1.10
(9.78 x 1.21 x 3.60)
1 365
(3009)
Rear outrigger, com-
plete with outrigger
beams, outrigger cylin-
ders and outrigger pads
(ROB)
2)
3.41 x 1.26 x 1.53
(11.19 x 4.13 x 5.02)
5 125
(11 300)
1)
Consists of two complete packets
2)
Additional equipment
