Starting/turning off the engine – for crane operation
10.2 Starting the engine – with the hand-held control
Operating manual GMK 6400 3 112 993 en 10 - 15
12.07.2013
10.2 Starting the engine – with the hand-held control
Requirements You can only start the engine, if:
– The bridging plug is inserted in all unneeded sockets;
à p. 10 - 4,
– The ignition in the driver's cab is switched off.
Starting the
engine
All checks required before starting the engine must be carried out;
à p. 4 - 1.
• Wait until the lamps (1) and (2) light up.
If the lamp (2) does not go on or flash after about 20 seconds, there is a mal-
function;
à p. 14 - 20.
Press the button (3) once – the engine starts.
H
If the hand-held control is connected to the superstructure, you cannot drive
the power units from the crane cab.
