Driving
5.1 Before driving
5 - 14 3 112 993 en Operating manual GMK 6400
12.07.2013
5.1.4 Switching the suspension on/off
The suspension is switched off whenever the ignition is switched off.
The suspension must be switched on for on-road driving.
The current switching state of the suspension is shown on the (1) displays
under the main menu and in the
Suspension submenu.
To switch the suspension on and off, you must open the
Level Adjustment
System
submenu.
Opening the
submenu
You can only open the submenu when the truck crane is stationary, or when
the current speed is below approx. 5 km/h (3 mph).
• If necessary, open the main menu ö and press the (1) button once.
This opens the
Level Adjustment System submenu.
The (1) dot indicates the selected switching state:
Symbol is green: The suspension is switched on
Symbol is red: The suspension is switched off
Dot is green: Switch on suspension has been selected
Dot is black: Switch off suspension has been selected
