Manitowoc GROVE GMK 6400 User Manual

Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual GMK 6400 3 112 993 en 9 - 73
12.07.2013
9.2.9 Outrigger pressure displays
Outriggers
submenu
Outrigger pressure display
Outriggers control
units
Outrigger pressure display
9.2.10 Anemometer display
This function is the same in all the menus.
The anemometer is electrically connected.
– Unit of measurement: Displayed depending on setting
– t – tons or
– klbs – kilopounds – (1 kilopound = 1000 lbs)
– Precision: One decimal place
à p. 12 - 57
– Unit of measurement: Lights up depending on setting
– t – tons or
– klbs – kilopounds – (1 kilopound = 1 000 lbs)
– Precision: When in t, one decimal place
When in klbs, no decimal point
à p. 12 - 57
1 Scale in meters per second (m/sec)
2 Beaufort scale (B)
3 Wind speed display
à p. 11 - 54
