Driving modes and rigging for on-road driving
6.5 Installing/removing the supporting box
6 - 56 3 112 993 en Operating manual GMK 6400
12.07.2013
11. If the main boom is to be set down on a trailer:
With the RCL set accordingly, slew the superstructure to the rear and
lower the main boom;
à Crane movements during installation and removal, p. 6 - 69.
12. On the outriggers:
– Retract the front outrigger cylinders and outrigger beams and secure;
à CHECKLIST: Retracting the outriggers, p. 12 - 31.
– Retract auxiliary support;
à Auxiliary supports, p. 6 - 60.
