Manitowoc GROVE GMK 6400 User Manual

Correction sheet GMK6400 3 113 150 en 1
21.07.2014
Axle load table All axle loads specified apply to 445/95 R 25 tyres and a reeved 1-sheave
hook block, weight 850 kg (1 875 lbs).
Counter-
weight
in t
(lbs)
Telescope Status
I - II - III - IV
in %
Main Boom
Angle
in °
Superstruc-
ture Position
1)
Axle Load
2)
in t (x 1.000 lbs)
front rear
15,0
(33 069)
44 - 0 - 0 - 0 5 front 14,5 (32,0) 14,2 (31,3)
0 - 0 - 0 - 44 82 rear 8,4 (18,5) 17,2 (37,9)
25
(55 116)
44 - 44 - 0 - 0 5 front 15,4 (34,0) 16,3 (35,9)
0 - 0 - 0 - 44 82 rear 11,1 (24,5) 18,5 (40,8)
35,0
(77 162)
88 - 0 - 0 - 0 15 front 13,5 (29,8) 19,7 (43,4)
0 - 0 - 0 - 44 82 rear 13,6 (30,0) 19,6 (43,2)
45
(99 208)
88 - 0 - 0 - 0 5 front 10,3 (22,7) 23,9 (52,7)
0 - 0 - 0 - 44 82 rear 16,2 (35,7) 20,9 (46,1)
55,0
(121 254)
not permitted front -- --
0 - 0 - 0 - 44 82 rear 18,7 (41,2) 22,1 (48,7)
75,0
(165 439)
not permitted front -- --
0 - 0 - 0 - 44 82 rear 23,8 (52,5) 24,5 (54,0)
95,0
(209 439)
not permitted front -- --
0 - 0 - 0 - 44 75 rear 26,8 (59,1) 28,0 (61,7)
over 95.0
(209 439)
Driving with rigged truck crane is not permitted
Unrig the counterweight combination to 95.0 t.
(209 439 lbs)
1)
Rear: Display slewing angle of 0°
Front: Display slewing angle of 180°
2)
Front: Each on the first and second axle line
Rear: Each on the third, fourth, fifth and sixth axle line
