3-6 Parts
Parts are designed to meet specific needs. Generally speaking, one component can realize one
function, but some components should be combined with the related components or PLC to realize
some specific functions, as shown below.
Most of the PLC part support “bit” or “word” addresses (“Double-word” operation can be performed by
some components such as Number Input and Scroll Bar etc. Due to some PLCs have “double-word”
addresses, so some PLC drivers will make conversion between “double-word” and “word”, and the user
must pay special attentions to the instructions of PLC driver.
Bit Button component defines one touching area. When this area is activated, the bit
address inside the PT or in the PLC can be switched to “On” or “Off” forcefully.
Components Related Components Descriptions
Number Input Function Key To create the keyboard by “Function Key”
Text Input Function Key To create the keyboard by “Function Key”
Indirect Screen Screen The created “screen”
Direct Screen Screen The created “screen”
Alarm Setting Alarm, Alarm Display To display the registered alarm information by “Alarm”
or “Alarm Display”
Alarm Alarm Setting To display the alarm information registered by “Alarm
Setting” component
Alarm Display Alarm Setting To display the alarm information registered by “Alarm
Setting” component
Event Setting Event To display the registered event by “Event” component
Event Event Setting To display the event registered by “Event Setting”
component
PLC Control PLC To make PLC program control the operations of the
functions
3-6-1 Bit Button
