Omron NB-series User Manual

3-327
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-11 Address of System Memory
3
3-11-3 Nonvolatile Local Word (LW10000~10255)
9506~9507 Authority setting Double-words and 32 authorities’ assignments.
LW9506 to LW9507 corresponds to 32 authorities (No.
0 to No. 31) and LW.B corresponds to each bit in
LW9506 to LW9507. For example: LW.B 9506.0
represents the authority of No. 0; and LW.B 9506.A
represents the authority of No. 10 (write).
9508~9509 Automatic Logout Time setting Sets the unit of automatic logout time to minute during
the addition of user information (write).
9510~9511 Password Confirm Inputs the password again for consistency confirmation
during the addition of user information (write).
9520~9521 Curser position Refers to the curser position (X
,Y) in input component
(read).
9535 The multiplication factor of the
communication time for the Macro
instruction
If it is specified to “N”, the maximum communication
time of the Macro external value is N times as long as
the default (read/write).
9536 The multiplication factor of the
communication time for writing operation
by the data transmission component
If it is specified to “N”, the maximum communication time
for writing operation by the data transmission
component is N times as long as the default (read/write).
9551~9554 Notifying error information Each bit corresponds to each error information. When
the bit turns ON, the bit indicates that the corresponded
error information occurs. Refer to 3-11-4 System
Information Table (Page 3-329) in NBDesigner
Operation Manual for details (read).
9800~9801 Error code of the triggering error (read/write)
3-11-3 Nonvolatile Local Word (LW10000~10255)
RTC
Addresses Descriptions Comments
10000 RTC (second) BIN code with effective value ranging from 0 to 59
(read/write)
10001 RTC (minute) BIN code with effective value ranging from 0 to 59
(read/write)
10002 RTC (hour) BIN code with effective value ranging from 0 to 23
(read/write)
10003 RTC (day) BIN code with effective value ranging from 0 to 31
(read/write)
10004 RTC (month) BIN code with effective value ranging from 1 to 12
(read/write)
10005 RTC (year) BIN code with effective value ranging from 1971 to
2037 (read/write)
10006 RTC (week) BIN code with effective value ranging from 0 to 6
(read/write)
Description of RTC:
Users can use the related “Component” to display the time. Pay attention to the effective range. The operation
when the values out of the effective range is not ensured.
For example: “second” can not be written as 78 (BIN), otherwise RTC will continue in sequence (78 79 80 ...),
which may result in unexpected error.
Addresses Descriptions Comments
