2 Installation and Startup of NB-Designer
2-4
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
2-3 Startup & Quit
This section provides a brief for startup and quit of NB-Designer.
Select [Start]-[All Programs]-[OMRON]-[NB-Designer]-[NB-Designer]. The startup can also be realized
by double clicking the shortcut icon on the desktop.
• The user should run this program as an administrator in operation system of Windows other than
Windows XP.
• When the NB-Designer is started for the second time, the project operated last time will be opened
automatically.
• During the first launch of NB-Designer, the following screen will be displayed.
To quit the NB-Designer can be realized by using any one of the following methods.
• Select [Exit] in the [File] menu.
• Click the button in the upper right corner of the main window.
• Double click the NB-Designer icon in the upper left corner of the main window.
• Click the NB-Designer icon in the upper left corner of the main window, and select [Close] from the
displayed control menu bar.
• Press the [Alt] key and [F4] key simultaneously.
Note When the edited data in the file is not saved, “Save the Current Project?” dialog box will pop up.
2-3-1 Starting Method
2-3-2 Quitting Method
