6 Descriptions of New Functions Added into NB-TW01B
6-2
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
6-1 New Added Functions
NB-Designer also supports the bitmap data directly calling the graphics from the external memory in
order to save the memory space of the PT.
For example:
Create a background picture named “background.bmp” and save it in the root folder of USB memory
(Here refers to USB1). Then the project will directly call the picture named “background.bmp” from USB
memory.
1
Copy the picture named “background.bmp” into the root folder of USB memory.
2
Create new graphics: Click the icon in the toolbar or select “Add Graphics” option in the
[Draw] menu; and enter “background” in the Name option, select “1” in State No. option and
check “Bitmap” in Type option after the [Add Graphics] dialog box pops up.
6-1-1 Using Graphics From External Memory
To Next Page
