3-353
3 Functions of NB-Designer
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-15 Download
3
3-15-2 Download via USB Memory
For more details of download via USB memory, refer to 3-2 Menus (Page 3-7) in NB-series Setup
Manual.
In the [NBDownload] dialog box, check the required contents in the [Select Section] option to download
the required files.
Data File: Refers to the data information of all the components created by the user in PT screen. Only
after this option is checked, the downloaded project can work normally.
LOGO File: Download the initial screen (LOGO screen) displayed when starting PT. If the update of the
LOGO screen is needed, check in the [LOGO file] check box and click [Download] to
download the screen.
3-15-2 Download via USB Memory
3-15-3 Specification of Downloading Contents
