3 Functions of NB-Designer
3-234
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
3-8 Project Database
Text Library can be used to store the text contents needed by the project, thus preventing
the label with the same text from being input frequently. In addition, Text Library can be used to the
conditions with the requirement of multi-language support to realize the switching among the multiple
languages for the PT Edit screen. NB-Designer currently supports up to 32 kinds of languages setting.
1
Text Input
(1) Pressing icon or clicking [Text Library] in the [Project Database] of the [Project
Library] allows the Text Library to pop up.
(2) When the following “Add Text” dialog box appears after “Add” being clicked, fill in the Title,
State No. and click “OK” to proceed to the next step.
Note Once the text title is registered, it cannot be modified in the [Text Library] dialog box.
3-8-1 Text Library
To Next Page
