3 Functions of NB-Designer
3-350
NB-series Programmable Terminals NB-Designer Operation Manual(V106)
The indirect online test is a method to obtain the data from the PLC through the PT and to test the
operations of PT. The indirect online test can obtain the data from the PLC dynamically, and the
operating environment is the same as that after the downloading except that the inconvenience of
downloading each time is avoided, thus it is quick and convenient, but it can’t be used independently
without the PT.
After the screen data is compiled, press the button, then the following dialog box will pop up:
Select the PT to be tested, and click the “Start” button to start the test. NB Unit performs the indirect
online test through the USB, Ethernet or serial port.
Caution It does not support the indirect online test with the other PLC than that manufactured by OMRON.
3-14-3 Indirect Online test
