No. Parameter
mask
Parameter
internal
Data type Meaning
24 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Type of feedrate: G group (G94/G95) for
surface and depth feedrate
0 = Compatibility mode
1 = G command as before cycle call.
G94/G95 same for surface and
depth feedrate
HUNDREDS:
0 = Compatibility mode
(enter <_CDIAM>/<_AP1> as ra‐
dius)
1 = Enter <_CDIAM>/<_AP1> as di‐
ameter
THOUSANDS: --- Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
25 <_AMODE> INT Alternative mode
UNITS: Pocket depth (Z1)
0 = Absolute (compatibility mode)
1 = Incremental
TENS: Unit for infeed width (DXY)
0 = mm
1 = % of tool diameter
HUNDREDS: Insertion depth for chamfering (ZFS)
0 = Absolute
1 = Incremental
3.25.1.7 SLOT1 - longitudinal slot
Syntax
SLOT1 (<RTP>, <RFP>, <SDIS>, <_DP>, <_DPR>, <NUM>, <LENG>, <WID>,
<_CPA>, <_CPO>, <RAD>, <STA1>, <INDA>, <FFD>, <FFP1>, <_MID>,
<CDIR>, <_FAL>, <VARI>, <_MIDF>, <FFP2>, <SSF>, <_FALD>, <_STA2>,
<_DP1>, <_UMODE>, <_FS>, <_ZFS>, <_GMODE>, <_DMODE>, <_AMODE>)
