Syntax
CTABEXISTS(<n>)
Meaning
CTABEXISTS: Checks for the presence of curve table number <n> in the static or dynamic NC
memory.
0 Table does not exist
1 Table exists
<n>: Number (ID) of curve table
3.16.2.3 Delete curve tables (CTABDEL)
CTABDEL can be used to delete curve tables.
Note
Curve tables that are active in an axis coupling cannot be deleted.
Syntax
CTABDEL(<n>)
CTABDEL(<n>,<m>)
CTABDEL(<n>,<m>,<memory location>)
CTABDEL()
CTABDEL(,,<memory location>)
Meaning
CTABDEL: Command for deleting curve tables
<n>: Number (ID) of the curve table to be deleted
When a curve table range CTABDEL(<n>,<m>) is deleted, <n> is used to
specify the number of the first curve table in the range.
<m>: When a curve table range CTABDEL(<n>,<m>) is deleted, <m> is used to
specify the number of the last curve table in the range.
<m> has to be greater than <n>.
<memory
location>:
Specification of memory location (optional)
In the case of deletion without a memory location being specified, the specified
curve tables are deleted in the static and the dynamic NC memory.
In the case of deletion with a memory location being specified, of the specified
curve tables, only those located in the specified memory location are deleted.
The rest are retained.
"SRAM" Deletion in the static NC memory
"DRAM" Deletion in the dynamic NC memory
Work preparation
3.16 Axis couplings
NC programming
902 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
