Procedure
1. Create a new part program (name)
2. Edit the part program
3. Select the part program
4. Activate single block
5. Start the part program.
Note
In order that the program can run on the machine, the machine data must have been
appropriately set (→ see machine manufacturer's data!).
Note
When testing a program, alarms can occur, which must first be reset.
NC program
Program code Comment
N10 MSG ("THIS IS MY NC PROGRAM") ; Message "THIS IS MY NC PROGRAM" dis-
played in the alarm line.
N20 F200 S900 T1 D2 M3 ; Feedrate, spindle, tool, tool off-
set, spindle clockwise.
N30 G0 X100 Y100 ; Approach position in rapid traverse.
N40 G1 X150 ; Rectangle with feedrate, straight
line in X.
N50 Y120 ; Straight line in Y.
N60 X100 ; Straight line in X.
N70 Y100 ; Straight line in Y.
N80 G0 X0 Y0 ; Retraction in rapid traverse.
N100 M30 ; End of block.
2.3.4.2 Example 2: NC program for turning
Program example 2 is intended for machining a workpiece on a lathe. It contains radius
programming and tool radius compensation.
Fundamentals
2.3 Creating an NC program
NC programming
54 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
