No. Screen
form pa‐
rameter
Cycle pa‐
rameter
Meaning
13 ST _DP Number of the replacement tool (duplo number) to be corrected
14 TZL S_TZL Work offset
2), 4)
15 DIF S_TDIF Dimensional difference check
2), 4)
16 TUL S_TUL Upper tolerance limit (incremental to the setpoint)
4)
17 TLL S_TLL Lower tolerance limit (incremental to the setpoint)
4)
18 TMV S_TMV Offset range for averaging
2)
19 FW S_K Weighting factor for averaging
2)
20 EVN S_EVNUM Number of the empirical mean value memory
2), 7)
21 S_MCBIT Reserved
22 _DMODE Display mode
Val‐
ues:
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane active before the cycle call remains active
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
23 _AMODE Alternative mode
Val‐
ues:
UNITS: Dimensional tolerance yes/no
0 = No
1 = Yes
1)
All default values = 0 or marked as default=x
2)
Display depends on the general SD54760 $SNS_MEA_FUNCTION_MASK_PIECE
3)
Correction in WO only possible for measurement without reversal
4)
For tool offset in the channel-specific MD 20360 TOOL_PARAMETER_DEF_MASK , observe bit0 and bit1
5)
Only if the "Setup additive offset" function has been set-up in the general MD 18108 $MN_MM_NUM_SUMCORR . In
addition, in the general MD 18080 $MN_MM_TOOL_MANAGEMENT_MASK , bit8 must be set to 1.
6)
If WO "fine" has not been set up in MDs, correction is according to WO "coarse"
7)
Empirical averaging only possible for tool offset
Value range for empirical mean value memory:
1 to 20 numbers (n) of the empirical value memory, see channel-specific SD55623 $SCS_MEA_EMPIRIC_VALUE[n-1]
10000 to 200000 numbers (n) of the mean value memory, see channel-specific SD55625
$SCS_MEA_AVERAGE_VALUE[n-1]
3.25.3.3 CYCLE994 measuring cycle parameters
PROC CYCLE994(INT S_MVAR,INT S_KNUM,INT S_KNUM1,INT S_PRNUM,REAL S_SETV,INT S_MA,REAL
S_SZA,REAL S_SZO,REAL S_FA,REAL S_TSA,INT S_NMSP,STRING[32] S_TNAME,INT S_DLNUM,REAL
S_TZL,REAL S_TDIF,REAL S_TUL,REAL S_TLL,REAL S_TMV,INT S_K,INT S_EVNUM,INT S_MCBIT,INT
_DMODE,INT _AMODE,INT _DP)
Work preparation
3.25 Programming cycles externally
NC programming
1160 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
