Technology Cycle screen form
Turning Thread turning: Longitudinal
Contour turning: Stock removal
Contour turning: Grooving
Contour turning: Groove turning
In the user interface of the relevant cycle screen forms, the options "Input: Simple" and "Input:
Complete" are available.
Cycle parameters that are not displayed
The cycle parameters that are not displayed in the simplified input are pre-assigned fixed,
technologically useful, but not variable values. Or the cycle parameters are assigned
parameterizable values via the channel-specific cycle setting data. See the paragraph below
"Commissioning" > "Channel-specific cycle setting data"
Switchover from "Input: Complete" > "Input: Simple"
If a cycle screen form is filled in with the setting "Input complete" and then switched to "Input
simple", the default or setting data values are used for the parameters no longer displayed
when generating the cycle call.
Commissioning
Channel-specific configuration machine data
The technology scaling in cycle screen forms can be activated with the machine data:
MD52210 $MCS_FUNCTION_MASK_DISP, bit 9 = 1 (select display "Input simple")
Channel-specific cycle setting data
If the simplified input in cycle screen forms is active, the values for certain cycle parameters can
be specified via the following setting data:
Number Identifier Meaning
SD55300 $SCS_EASY_SAFETY_CLEARANCE Safety clearance
SD55301 $SCS_EASY_DWELL_TIME Dwell time
SD55305 $SCS_EASY_DRILL_DEEP_FD1 Deep-hole drilling: Percentage: 1st feedrate
SD55306 $SCS_EASY_DRILL_DEEP_DF Deep-hole drilling: Percentage: Infeed
SD55307 $SCS_EASY_DRILL_DEEP_V1 Deep-hole drilling: Minimum depth infeed
SD55308 $SCS_EASY_DRILL_DEEP_V2 Deep-hole drilling: Retraction distance
SD55309 $SCS_EASY_THREAD_RETURN_DIST Thread turning: Return distance
3.25.2 Measuring cycles
Measuring cycles are special subprograms provided by Siemens to solve certain measuring
tasks. As with cycles in general, measuring cycles can also be adapted to specific problems via
parameter settings.
Work preparation
3.25 Programming cycles externally
NC programming
1154 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
