7)
Diameter or width of the protection zone within a hole or groove
Diameter or width of the protection zone outside of a spigot or rib
8)
Empirical averaging possible for tool offset
Value range for empirical mean value memory:
1 to 20 numbers (n) of the empirical value memory, see channel-specific SD55623 $SCS_MEA_EMPIRIC_VALUE[n-1]
10000 to 200000 numbers (n) of the mean value memory, see channel-specific SD55625
$SCS_MEA_AVERAGE_VALUE[n-1]
3.25.3.8 CYCLE961 measuring cycle parameters
PROC CYCLE961(INT S_MVAR,INT S_KNUM,INT S_PRNUM,REAL S_SETV0,REAL S_SETV1,REAL
S_SETV2,REAL S_SETV3,REAL S_SETV4,REAL S_SETV5,REAL S_SETV6,REAL S_SETV7,REAL S_SETV8,REAL
S_SETV9,REAL S_STA1,REAL S_INCA,REAL S_ID,REAL S_FA,REAL S_TSA,INT S_NMSP,INT S_MCBIT,INT
_DMODE,INT _AMODE)
Table 3-15 CYCLE961 call parameters
1)
No
.
Screen
form pa‐
rameter
Cycle pa‐
rameter
Meaning
1 S_MVAR Measuring variant (default ≥ 6)
Val‐
ues:
UNITS: Contour element
5 = Setup of right-angled inside corner, setpoint specification of angle and distan‐
ces A1 to A3
6 = Setup of right-angled outside corner, setpoint specification of angle and dis‐
tances A1 to A3
7 = Setup of inside corner, specification of angle and distances A1 to A4
8 = Setup of outside corner, specification of angle and distances A1 to A4
TENS: Setpoint specification as distance or via four points
0 = Setpoint specification as distance (polar)
1 = Setpoint specification using four points (measuring points P1 to P4)
HUNDREDS: Correction target
0 = Only measurement (no correction of the WO or no tool offset)
1 = Measurement and determination and correction of the WO, see S_KNUM
THOUSANDS: Protection zone
0 = No consideration of a protection zone (obstacle)
1 = Consideration of a protection zone (obstacle), see S_ID
TEN THOUSANDS: Position of the corner in the WCS
0 = Position of the corner is determined via parameter S_STA1 (compatibility)
1 = Position 1 of the corner in the positioned starting point of the measurement
6)
2
= Position 2 of the corner, distances in the 1st axis of the plane (for G17 X) are
negative (see S_SETV0, S_SETV1)
3 = Position 3 of the corner, distances in the 1st and 2nd axis of the plane (for
G17 XY) are negative (see S_SETV0 to S_SETV3)
4 = Position 4 of the corner, distances in the 2nd axis of the plane (for G17 Y) are
negative (see S_SETV2, S_SETV3)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1175
