4.1 Operations
Note
Cycles
The list of operations contains all cycles, which occur in the NC program (G code), i.e. can be
programmed in the program editor using masks - or must be programmed for loops without
programming support. Cycles, which for reasons of compatibility, are still available in the
control, however can no longer be edited using the SINUMERIK Operate program editor
("compatibility cycles") are not taken into account.
Operations A ... C
Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
: O NC main block number, jump label termina‐
tion, concatenation operator
+/- PM-NC
* O Operator for multiplication +/- PM-NC
+/- O Operator for addition +/- PM-NC
- O Operator for subtraction +/- PM-NC
< O Comparison operator, less than +/- PM-NC
<< O Concatenation operator for strings +/- PM-NC
<= O Comparison operator, less than or equal to +/- PM-NC
= O Assignment operator +/- PM-NC
>= O Comparison operator, greater than or equal to +/- PM-NC
/ O Operator for division +/- PM-NC
/0
…
…
/7
block is skipped (1st skip level)
...
...
block is skipped (8th skip level)
+/- PM-NC
A A Axis name m/s +/- PM-NC
A2 A Tool orientation: RPY or Euler angle s +/- PM-NC
A3 A Tool orientation: 1st component of the direc‐
tion vector
s +/- PM-NC
A4 A Tool orientation: 1st component of the surface
normal vector at start of block
s +/- PM-NC
A5 A Tool orientation: 1st component of the surface
normal vector at end of block
s +/- PM-NC
A6 A Tool orientation: 1st component of the direc‐
tion vector for taper's axis of rotation
s +/- PM-NC
