4.3.8 G group 8: Settable work offset
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G500 1 Deactivation of settable work offset (G54 to G57, G505
to G599)
+ m x
G54 2 1st settable work offset + m
G55 3 2nd settable work offset + m
G56 4 3rd settable work offset + m
G57 5 4th settable work offset + m
G505 6 5th settable work offset + m
... ... ... + m
G599 100 99th settable work offset + m
Each of the G commands in this G group is used to activate an adjustable user frame $P_UIFR[ ].
G54 corresponds to frame $P_UIFR[1], G505 corresponds to frame $P_UIFR[5].
The number of adjustable user frames and therefore the number of G commands in this G group can be set using machine
data MD28080 $MC_MM_NUM_USER_FRAMES.
4.3.9 G group 9: Frame and tool offset suppression
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G53 1 Suppression of current frames:
Programmable frame including
system frame for TOROT and TOFRAME and
active adjustable frame (G54 to G57, G505 to G599)
- s
SUPA 2 As for G153 including suppression of
system frames for actual value setting, scratching, ex‐
ternal work offset, PAROT including handwheel offsets
(DRF), [external work offset], overlaid movement
- s
G153 3 As for G53 including suppression of all channel-specif‐
ic and/or NCU-global basic frames
- s
SUPD 4 Suppression of the active tool offsets - s
4.3.10 G group 10: Exact stop - continuous-path mode
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G60 1 Exact stop + m x
G64 2 Continuous-path mode + m
G641 3 Continuous-path mode with smoothing according to
distance criterion (= programmable rounding clear‐
ance)
+ m
Tables
4.3 G commands
NC programming
1250 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
